• Product Name: BS4504 Flange Type Rubber Joint
• Model Number: RJ002
• Brand Name: RubberJoint
• Place of Origin: Tianjin, China
• Minimum Order Quantity: 10 PCS
• Supply Capacity: 200 Tons/month
• Payment: T/T,L/C
• MemberShip: Free Member
• Inquiry Now
• Bookmark & Share:

BS4504 Flange Type Rubber Joint RJ002 Description

Our Range:Butterfly Valve,Gate Valve,Check Valve,Globe Valve,Ball Valve,Y Strainer,Rubber Joint

Main parts materials

Rubber: EPDM/NBR/Neoprene

Carcass: Nylon Cord Fabric

Reinforcing wire: Spring Steel wire

Flange Type: Carbon steel, Zinc Plated (DIN2501,ANSI B16.5,JIS etc)

Union Type: Malleable iron, zinc plated (DIN2999,NPT,BSP etc)

Technical information

Working Pressure: 10Bar,16Bar,25Bar

Burst Pressure: 30Bar,48Bar,55Bar

Vaccum: 400mmHg,650mmHg,750mmHg

Temperature: EPDM(-10 to 120 degree),NBR(-10 to 82 degree),Neoprene(-10 to 110 degree)

Medium: Air,Water,Oil,Acid,Alkali and etc.
