• Product Name: Spherical Disc High Performance Butterfly Valve
• Model Number: QD342Y-150C
• Brand Name: QUANSHUN
• Place of Origin: Henan, China
• Minimum Order Quantity: 2
• Supply Capacity: 200 Sets/Week /month
• Payment: T/T
• MemberShip: Free Member
• Inquiry Now
• Bookmark & Share:

Spherical Disc High Performance Butterfly Valve QD342Y-150C Description

Spherical Disc High Performance Butterfly Valve  is developed based on the mechanism of the butterfly valve and segment ball valve . The special butterfly valve can be used at inlet of the water pump,piping network system,recovery stem,high water tank,sewage system and the back flow prevention to shut off or control the pipeline.

FEATURES
 1.Designed with bidirectional sealing structure,the installation of the high performance butterfly valve will not be restricted by the direction of the fluid.
 2.Since the metal bi-directional sealing butterfly valve is offered with self-sealing device,reliable sealing performance can be realized under the pressure from medium.
 3.Powerful specific pressure of sealing can be obtained the valve is installed on the direction in opposite to that of the fluid.The pressure acts on the valve seat of the bidirectional rotary ball valve. The contact area of the point action is annular,
 4.The spherical disc butterfly valve has long service life due to wear compensation.
 5.The unique rotational structure  ,as well as the sphere-conical sealing surface of the valve seat,makes for the cleaning function the solid particle will be crushed when the electric operated bidirectional rotary ball valve is opened or closed.

TECHNICAL PARAMETERS

 Body material ：WCB, CF8, CF8M, CF3, CF3M,etc.
 Sealing material：Hard alloy
 Connection type：Flange and weld
 Operating type：manual ,electric or pneumatic
 Nominal Diameter ：2”~40” DN50~DN2000
 Pressure：Class 150~Class 300   PN1.0~PN4.0

 APPLICATION

 Municipal Engineering
 Circulating water system
 Water treatment system
 Fire extinguisher system
