• Product Name: Pneumatic Ceramic knife gate valve
• Model Number: pz673tc-150lb
• Brand Name: ZC
• Place of Origin: Zhejiang, China
• Minimum Order Quantity: 1 SET
• Supply Capacity: 5000/month
• Payment: T/T
• MemberShip: Free Member
• Inquiry Now
• Bookmark & Share:

Pneumatic Ceramic knife gate valve pz673tc-150lb Description

Characteristics

This valve is application as an on-off media containing high –hardness grains ,such as cinder water , or for pipelines with both soft grains and corrosive media .its nominal pressure is 1.0 Mpa ,and application temperature≤150℃ 。the sealing surface adopts had seal , and all medium contacting parts are made of structural ceramic withextremely high chemical stability and hardness .Therefor , it has extremely strong resistance to abrasion ,corrosion and erosion .good heat insulation and small thermal expansion . Its feed inlet is fully through without any blocks and it has strong abrasion resistance a good seal ability and a small strating load , with little ash seizure or accumulation .It adopts a high-grace toughened structural ceramic seal ,featuring high mechanical  strength  ,strong abrasion resistance ,a long service life and a compact structure which can be installed at any angle

Material for main Parts

Item

Name

Material

Item

Name

Material

1

Body

WCB

6

Stem

Q235+Hcr

2

Disc

Ind+Ceramic

7

Yoke

Q235

3

Seat

8

8

Nut

10

4

Packing

PTFE

9

Traval Switch

Assemble

5

Packing Gland

WCB

Pneumatic

Assemble

Application Specification

Design & Manuafcture

GB/ T 8691

Connection end dimension

Face to face

GB/T 15188.2

Flange dimension

Gb/T9113.1

Inspect & Test

JB/T 8691

Material

Carbon Steel

GB/T 12229

Stainless Steel

GB/T12230

Mark

GB/T12220

Supply

GB/T12252
