• Product Name: Pneumatic ceramic feed valve
• Model Number: WZ644TC-150LB
• Brand Name: ZC
• Place of Origin: Zhejiang, China
• Minimum Order Quantity: 1 SET
• Supply Capacity: 5000/month
• Payment: T/T
• MemberShip: Free Member
• Inquiry Now
• Bookmark & Share:

Pneumatic ceramic feed valve WZ644TC-150LB Description

Characteristice:

This valve is applicable for discharge and transportation of dry ash systems in power plants and storehouse pump, or can be used as an on-off for pipelines containing abrasive dry ash, water(such as cinder water) and the like in mines. Papermaking, chemical engineering and so on, Its working nominal pressureis 1.0MPa, applicable temperature≤200℃,and airsupply pressure 0.6-0.8MPa.

After the valve is closed, it’s fully sealed in any direction. Its middle body adopts WCB steel casting and seamless steel pipe welding, Its sealing surface adopts a hard sealing element.

Its feed inlet is fully through without any biocks, and it has an anti blockage blowing unit, with strong abrasion resistance, a good seal ability, a small starting load and with little ash seizure or accumulation.

It adopts a high-grade toughened structural ceramic seal. Featuring high mechanical strength, strong abrasion resistance, a long service life and a compact structure, which can be installed at any angle.

Materials for main parts

Item

Name

Material

Item

Name

Material

1

Body

WCB

7

Middle body

WCB

2

Plate

Composite engineering ceramic

8

Packing

Flexible Graphite

3

Seat

Composite engineering ceramic

9

Packing gland

2Cr13

4

Stem

2Cr13

10

Bracket

Q235

5

Stud

35CrMoVA

11

Pneumatic device

6

Nut

25

Application specification

Design and manufacture

CB/T12224

Connection end dimension

Structural length

Manufacturer’s standard

Flange dimension

JB/T 79.1

Inspection and test

GB/T 9092

Material

Carbon steel

GB/T 12229

Stainless steel

GB/T 12230

Mark

GB/T 12220

Supply

GB/T 12252
