• Product Name: G1/8" - G11/2" Solenoid Air Valve
• Model Number: GG-005
• Brand Name: GOGO ATC
• Place of Origin: Zhejiang, China
• Minimum Order Quantity: 50 Pieces
• Supply Capacity: 40000 Pieces/month
• Payment: L/C,D/A,D/P,T/T,Western Union,MoneyGram
• MemberShip: Free Member
• Inquiry Now
• Bookmark & Share:

G1/8" - G11/2" Solenoid Air Valve GG-005 Description

SLB high temperature or low temperature liquid (gas) nitrogen (N2), oxygen (O2), carbon dioxide (CO2) solenoid valve

SLB high (low) temperature solenoid valve

Product description:

SLB series solenoid valve, the product for a series of production, large flow, good practicality, widely used in the steam, heat conduction oil and other high temperature, and low temperature and other fluid control. Made of imported high temperature resistant tetrafluoroethylene diaphragm structure, through the medium of excellent performance. High temperature resistant coil, and thermal protection, ensure long life, high reliability.

The main technical parameters:

1. Two-position two-way, Normally closed solenoid valve,Power off, power on.

Products for the production of a series of small, large flow, a wide range of use,

2. Body material:copper, parts for stainless steel.

3. Ambient temperature:-20~65℃

4. Medium temperature: Low temperature:-100 °C~10°C

High temperature:99℃~200℃

5. Applicable medium:High temperature steam, heat conduction oil, etc., low temperature such as liquid (gas) nitrogen (N2), oxygen (O2), carbon dioxide (CO2), etc..

6. Install:Press the arrow mark on top of the valve can be any installation, to enhance the service life, best coil upward horizontally.

7. Voltage:AC24V/110V/220V/230V/240V 50/60HZ DC24V/12V
