dn15 brass CWX-15Q 3-way motorized ball Valve
- Product Name: dn15 brass CWX-15Q 3-way motorized ball Valve
- Model Number: CWX15N/Q
- Brand Name: CWX
- Place of Origin: Tianjin, China
- Minimum Order Quantity: 1 Piece
- Supply Capacity: 20000 Piece/month
- Payment: L/C,D/A,D/P,T/T,Western Union,MoneyGram,paypal
- MemberShip: Free Member
- Inquiry Now
dn15 brass CWX-15Q 3-way motorized ball Valve CWX15N/Q Description
dn15 brass CWX-15Q 3-way motorized ball Valve for Commercial,
Industrial, and Sanitary Applications Electric Actuated Ball Valves
1/2" Stainless Steel 110 VAC New
Stainless Steel Motorized Ball Valve specifications:
120 Volt
2-way
Housing Material ABS Body/Ball/Stem CPVC
316 Stainless Steel Valve
1/2", 3/4", and 1" NPT (Female)
Seal EPDM dn15 brass CWX-15Q 3-way 3 way motorized ball Valve
Rating IP67
Seat PTFE
Max Power 5 W
Max Torque 2 Nm
2 wires normally closed function
Visual indicator and manual override
100000 times service life.
Maximum Pressure 232 psi
Max Delta P is 100 psi
Ambient Temp -4F to 113F (-20C to 45C)
Maximum Temperature 140F (60 C)
Current 25 +/- 5 mA
To fully close Running Time 5 t0 7 seconds
Open amp; close time: 3 to 5 seconds. Anti water hammer slow close function. Without costly and bulky spring return actuator, the valve will normally close by the way of built in capacitor when power off
Max Temperature: 100 C (212 F)
Very low working current, can be suitable for battery operating.
Small amp; compact design, very suitable for small equipment.
To guarantee the best working performance, charge the valve for 60 seconds when you first use the valve.
The dn15 brass CWX-15Q 3-way motorized ball Valve design as an economical alternative to solenoid valves for use in popular applications:
High fouling heating & cooling water systems
Different water control system
Water recycling
Water purification
Water treatment.
Center heating & cooling water system
HVAC
Automated leak detection
Water shut off system electric brewing system
Solar heating systems
Campus IC card systems
Water saving systems
Automatic irrigation
Water purification & filtration systems
Sprinkle systems
| Material | brass or SS304 Stainless Steel |
|---|---|
| Temperature of Media | Medium Temperature |
| Port Size | 1/2 to 1 |
| Output torque | 1.5~6NM |
| Actuator rotation | 90/180 degree |
| Control mode | 2,3,5 wires(CR01/02/03/04/05/06) |
| Low Working Current | 80mA~150mA |
| Rated Volotage | DC3-6V/AC/DC9-24V |
| Rated current | 45-100MA |
| Open/close time | 3-5seconds |
