Slurry pumps for mining project Sales6@tobeepump.com
- Product Name: Slurry pumps for mining project Sales6@tobeepump.com
- Model Number: 3x2C-TH Slurry Pump
- Brand Name: TOBEE
- Place of Origin: Hebei, China
- Minimum Order Quantity: 1
- Supply Capacity: 1000/month
- Payment: T/T
- MemberShip: Free Member
- Inquiry Now
Slurry pumps for mining project Sales6@tobeepump.com 3x2C-TH Slurry Pump Description
Alice
Email: | Mob: +86-13833117806 | Skype: Sales6_867| Fax: +86 311-87221317
Web: www.tobeepump.com | Web: www.slurrypumpsupply.com | Web: www.tobee.cc | Web: www.hydroman.cn
3x2C-TH Slurry PumpSPECIFICATIONS:Size: 3" x 2" Capacity: 39.6-86.4m3/h Head: 12-64m Speed: 1300-2700rpm NPSHr: 4-6m Eff.: 55% Power: Max.30kw Handling solids: 25mm Seal arrangement: Packing seal, Expeller seal, Mechanical seal
3/2C-AH Slurry Pump is a heavy-duty slurry pump designed to handle the most abrasive and dense slurries. The 3/2C-AH slurry pump offers users a wide range of seal and liner configurations, allowing the pump to be fully customized to meet any specific application requirements. 3/2C-AH slurry pumps offer unmatched power consumption, long component life, and unmatched reliability.
Design Features:
√ Bearing assembly- large diameter shaft with short overhang contributes to long bearing life.
√ Liners – easily replaceable liners are bolted, not glued to the casing for positive maintenance.
√ Casing – casing halves of cast or ductile iron provide high operating pressure capabilities.
√ Impeller – front and rear shrouds have pump out vanes that reduce recirculation and seal contamination.
√ Throat bush – wear is reduced and maintenance simplified by the use of tapered
| Material | High chrome alloy |
|---|
