• Product Name: LW Sewage vertical pump
• Model Number: 100LW100-25-11
• Brand Name: kenshine-pump
• Place of Origin: Shanghai, China
• Minimum Order Quantity: 1Set
• Supply Capacity: 1000Sets per month/month
• Payment: T/T IN ADVANCE
• MemberShip: Free Member
• Inquiry Now
• Bookmark & Share:

LW Sewage vertical pump 100LW100-25-11 Description

Sewage vertical Pump

LW sewage pump is a kind of impurity pump. LW sewage pump has the single or double blades of impeller. So, the flow channel is wide and easy to transport sewage with fiber or other suspended impurities. In addition, there are inspection and cleaning holes on the shell of the pump body, so as to remove the dirty impurities inside the pump shell after the shutdown.

features:

Energy saving: The power curve is flat, which can run in the full performance range without overload.

No clogging, good anti-winding performance, single blade, large flow impeller. It can smoothly transport liquid containing large particles, food plastic bags, such as long fiber or other suspended matter. It can pump diameter of 100-250mm, fiber length of 300-1500mm of large particles solid block. The pump is suitable for conveying municipal sewage, industrial and mining enterprise sewage, mud, excrement, ash and slurry. The pump can also be used as a circulating pump, water supply and drainage pump and other purposes.

working conditions:

Flow: 2 to 1500m 3 /h

Head range: 3 to 45m

Rated speed N: 970 to 2900r/min

Medium temperature: -15℃ to +60℃

Medium density: ≤1.3×10 3 kg/m 3

Medium PH value: 5 to 9

High working pressure of system: ≤ 0.6mpa
