FP RPP corrosion resistant centrifugal pump 80FPD-32 Description

FP reinforced polypropylene anti-corrosive centrifugal pump uses a high-quality reinforced polypropylene (RPP) injection molding with high mechanical strength, good corrosion resistance, (the medium does not contact with the metal), with corrosion resistance, wear resistance, with high quality silicon carbide mechanical seal, without cooling water cooling, high efficiency, low price etc. FP reinforced polypropylene plastic centrifugal pump is used to replace stainless steel pump and fluorine alloy pump products and other non-metallic pump.

FP reinforced polypropylene anticorrosion centrifugal plastic pump is widely used to transport a large number of inorganic and organic acids, alkali, salt solutions and their derivatives. The pump can operate reliably in the range of -20 to 80DegC. The model 80FPD-32 (100FPD-32) is the best matching pump for the RPP-65 (RPP-80) series water jet vacuum pump.

FP Series reinforced polypropylene centrifugal pump is with mechanical seal. The pump is made from CFR-PP (reinforced polypropylene)material on the advanced domestic and oversea technology. The pump has the advantages of advanced structure, light weight, small volume and long life etc and widely used to transfer the acid and alkali ad salts etc corrosive liquids in the chemical industry, foodstuff, brewage, pharmacy, electroplate, papermaking, environmental protection, water treatment etc.

ModelinletoutletFlow(m3/h)Head(m)Motor power(KW)Speed(rpm)Efficiency(%)Suction   height(m)Connection20FPD-52015150.182900425closed coupling20FPD-62015360.372900435closed coupling25FPD-1025253.5100.55/0.752900465closed coupling32FPD-1132254110.752900465closed coupling40FPD-18403212181.5290054.436closed coupling40FPD-22403212222.2290055.636closed coupling40FPD-25403210252.2290055.636closed coupling40FPD-30403210303290051.746closed coupling50FPD-22504018222.2290051.746closed coupling50FPD-28504022283290051.746closed coupling50FPD-30504015303290051.746closed coupling65FPD-26655025263290051.746closed coupling65FPD-28655025284290051.746closed coupling80FPD-30806545305.5290068.84closed coupling80FPD-32806550327.5290069.94closed coupling100FPD-201008010020112900754closed coupling100FPD-321008010032152900764closed coupling40FP-18403212181.5290054.436shaft  coupling40FP-25403218253290055.636shaft  coupling40FP-32403210323290054.436shaft  coupling50FP-22504018222.2290051.746shaft  coupling50FP-28504022284290051.746shaft  coupling50FP-50503212.5507.52900396shaft  coupling65FP-28655025284290051.746shaft  coupling65FP-5065402550112900514shaft  coupling80FP-30806545305.5290068.84shaft  coupling80FP-32806550327.5290068.94shaft  coupling80FP-5080505050152900604shaft  coupling100FP-201008010020112900754shaft  coupling100FP-321008010032152900764shaft  coupling100FP-40100801004018.5290076.24shaft  coupling100FP-501006510050302900734shaft  coupling

Flow rate	2-100m3/h
Head	3-50m
pump material	FRPP/Polypropylene plastic
centrifugal pump	chemical pump
transfer pump	circulating pump
corrosion resistant pump	acid pump
alkali pump	anticorrosion pump
china pump	kenshine-pump
