• Product Name: FP polypropylene plastic chemical transfer centrifugal pump
• Model Number: 80FP-32
• Brand Name: kenshine-pump
• Place of Origin: Shanghai, China
• Minimum Order Quantity: 1SET
• Supply Capacity: 1000Sets per month/month
• Payment: T/T in advance
• MemberShip: Free Member
• Inquiry Now
• Bookmark & Share:

FP polypropylene plastic chemical transfer centrifugal pump 80FP-32 Description

FP Series polypropylene reinforced plastic chemical transfer centrifugal pump with shaft coupling

FP Series reinforced polypropylene corrosion resistance centrifugal pump
Summary:
FP Series reinforced polypropylene corrosion resistance centrifugal pump has the advantages such as advanced structure, small volume, light weight, energy-saving and good seal and corrosion resistance etc. The pump is widely used to transport the acid and alkali and salt etc corrosive liquids in chemical industry and light industry and waste dealing etc. FP Series reinforced polypropylene centrifugal and FS Series etc pumps all use the mechanical seal and are made from CFR-PP (Reinforced polypropylene) and ABS(Engineering plastic) etc.

The 104 pump with 220V can be in domestic use.

Parameter:

Model    Pump caliber    Flow rate    Head    Suction height    Speed    Voltage    Motor Power

Inlet    Outlet    m³/h    M    M    rpm    v    KW

FP20-15-100(105)    20    15    3    7    4    2900    380    0.75

FP32-25-100(104)    32    25    4    7    6.5    2900    220    0.55

FP32-25-105(103)    32    25    6.3    8    6.5    2900    380    0.75

FP40-32-125(102)    40    32    12.5    20    6.5    2900    380    1.5

FP50-40-130(101.5)    50    40    13    22    6.5    2900    380    2.2

FP65-50-150(101)    65    50    25    25    6    2900    380    4

50FP-22    50    40    13    22    6    2900    380    2.2

65FP-25    65    50    20    25    6    2900    380    4

80FP-28    80    65    50    28    4    2900    380    5.5

80FP-32    80    65    50    32    4    2900    380    7.5
