Class 150 Knife Gate Valve
- Product Name: Class 150 Knife Gate Valve
- Model Number: GLK08
- Brand Name: Guanli Valve
- Place of Origin: Zhejiang, China
- Minimum Order Quantity: 1 Set
- Supply Capacity: 10000 Sets/month
- Payment: Visa, T/T, L/C, Western Union
- MemberShip: Free Member
- Inquiry Now
Class 150 Knife Gate Valve GLK08 Description
GUANLI Class 150 Knife Gate Valve GLK08 product line is for tough applications such as solids, slurries, wastewater, bulk handling, pulp and paper, and food processing. Valves are available in wafer or lug style, as well as with ductile iron bodies or stainless steel bodies.
FEATURES AND OPTIONS
Handwheel or cylinder operated from 2" through 48" (custom sizes upon request)
Stainless or cast steel body options
Designed to ensure non-clogging shut-off with solids in the pipeline
ANSI 150# flanged drilling
EPDM, BUNA-N, Viton seat options to suit virtually any application
Limit switches, modulating positioners, NAMUR solenoids and many other custom options available
| Material | Casting |
|---|---|
| Pressure | Low Pressure |
| Temperature of Media | Low Temperature |
| Body | CF8M/CF8 |
| Knife | SS316/SS304 |
| Yoke | ANSI 1045+epoxy powder |
| Connection | AMSE B16.5 |
| Standard | MSS SP81 |
