Cast Iron Globe Valve Cast Iron Globe Valve Description

Cast Iron Globe Valve

Tanghai valve offers a wide variety of designed multi-turn valve configurations in stainless and carbon steel, along with virtually every special alloy required for difficult fluid compositions and high-pressure, high-temperature applications.

We provide cast and forged globe valves that are designed, engineered and manufactured in strict accordance with national piping standards.

Application：Petroleum Refineries, Chemical processing plants, Power generating plants.

Design and Manufacture Conform to MSS SP-85

Flange dimensions Conform to ANSI B16.1 CLASS125

Face to Face dimensions Conform to ANSI B16.10

Testing Conform to MSS SP-85

Sutiable Media: Water, Oil, Gas

MATERIALS OF PARTS

Number

Part Name

Material

1

Body

ASTM A126 B

2

Seating ring

Brass

3

Disc ring

Brass

4

Disc ring

ASTM A126 B

5

Locking nut

Brass

6

Stem

ASTM A276 420

7

Body gasket

08≠Steel+Graphite

8

Packing

Graphite

9

Bolts

Steel

10

Packing gland

ASTM A536 65-45-12

11

Bonnet

ASTM A126 B

12

Stem nut

Brass

13

Handwheel

ASTM A126 B

14

Bolts

Steel

SIZE

2"

2.5"

3"

4"

5"

6"

8"

10"

L

203

216

241

292

330

356

495

622

D

152

178

191

229

254

279

343

406

D1

120.7

139.7

152.4

192.5

215.9

241.3

298.5

362

D2

71.45

82.6

101.6

133.4

152.4

181

234.95

292.1

b

15.8

17.5

19.1

23.9

23.9

25.4

28.6

30.2

n-d

419

419

4-19

8-19

8-22

8-22

8-22

12-25
