Tobee replace Warman Slurry Pump WRT Impeller G10145WRT1A05 12/10ST-AH Description

Sales7(at)tobeepump.com

Tobee® Slurry Pump WRT Impeller G10145WRT1A05 is closed type with 4 vanes for 12X10ST-AH Centrifugal Slurry Pumps. Its design incorporates a unique vane let on the back shroud which streamlines the flow through the impeller.



WRT1 Impeller Wear Parts Code List:

AH Slurry Pump

WRT1 Impeller Code

Standard impeller Code

3x2C-AH

C2145WRT1A05

C2147A05

4x3C-AH,4x3D-AH

D3145WRT1A05

D3147A05

6x4D-AH,6x4E-AH

E4145WRT1A05

E4147A05

8x6E-AH

F6145WRT1A05

FAM6147A05

10x8F-AH

FAM8145WRT1A05

FAM8147A05

10x8ST-AH

G8145WRT1A05

G8147A05

12x10ST-AH

G10145WRT1A05

G10147A05

14x12ST-AH

G12145WRT1A05

G12147A05

16x14TU-AH

GAM14145WRT1

GAM14147A05

16x14H-AH

H14145WRT1

H14147A05



Tobee® WRT Spare Parts Wear Reduction Technology:

• Increased wear life – the impeller and throat bush combination will increase wear life between 30% and 50%

• Power savings – lower pump power consumption

• Cost reduction – higher pump efficiency sustained over a longer pumping operation time

• Retrofit – new design parts retrofit to your current AH slurry pumps

• Lower NPSH requirements – results in enhanced hydraulic performance and extended wear life

• Material combinations – rubber or metal part combinations available



Impeller design:


The five vane impellers in the AH pump range were for many years considered to be the industry ‘standard’. However, in order to improve upon one or more of the performance parameters, Tobee started out by using a range of four vane impellers developed for the AH pumps.

The latest WRT® impeller designs maintain the four vane’s advantages, but improved on all of the performance parameters - efficiency, wear and cavitation performance by improving the fluid guidance through the impeller with streamlined main pumping vanes, streamlined inlet as well as vane lets at the impeller outlet.

Due to these improvements in performance, the WRT® impellers represent a step change improvement compared to the older style five vane impeller design.



Slurry Pump Spare Parts WRT Impeller Applications:

The WRT series Impeller is used for highly abrasive/density slurries in processes from cyclone feed to regrind, mill discharge, flotation, mine drainage and tailing in minerals plants plus other industrial applications, Sometimes, it could also be used in dredging of settling lagoons and pumping of drilling mud etc.
