Tobee 8/6E-AH Rubber Heavy Duty Slurry Pumps
- Product Name: Tobee 8/6E-AH Rubber Heavy Duty Slurry Pumps
- Model Number: 8/6E-AH
- Brand Name: Tobee
- Place of Origin: Hebei, China
- Minimum Order Quantity: 1
- Supply Capacity: 2000/month
- Payment: T/T
- MemberShip: Free Member
- Inquiry Now
Tobee 8/6E-AH Rubber Heavy Duty Slurry Pumps 8/6E-AH Description
Sales7(at)tobeepump.com
8/6E-AH Rubber Heavy Duty Slurry Pump with anti-corrosive rubber wetted parts for for handling strong corrosive or abrasive slurries of small particle size without sharp edges in the mining.
8/6E-AH Rubber Lined Slurry Pump is the standard heavy duty slurry pumps which designed for the continuous pumping of highly abrasive, high density slurries with minimal maintenance requirements, It maintains high efficiencies over the wear life of its components. 8/6 slurry pump typically used in process plant transfers, wet waste processes, recycling-washing plants, sand plant duties, heavy minerals processing, mineral recovery and chemical process plant.
Design Features:
√ Heavy duty construction with through-bolt design provides ease of maintenance and minimal downtime
√ Ductile iron fully lined casing provides durability, strength, safety, and long service life
√ Large diameter, slow turning, high efficiency impellers designed to achieve maximum wear life and low operating costs
√ Large, open internal passages designed to reduce internal velocities, maximize wear life and lower operating costs
√ Thick rubber or alloy bolt-in liners provide superior corrosion
resistance plus offer ease of liner change-out and interchangeability to
reduce overall maintenance costs and maximize wear life
√ Minimal shaft/impeller overhang reduces shaft deflection and increases packing life
√ Cartridge-style bearing assembly allows for maintenance in a clean
environment without removal of the pump, resulting in reliable operation
and prolonged bearing life
√ Grease or oil lubrication bearing assembly options offer ease of maintenance and reduced downtime
√ Optional dry running shaft seal reduces or eliminates flush water requirements
√ Effective expeller prolongs packing life while reducing or eliminating flush water requirement
8/6E AH Rubber Lined Slurry Pumps Applications:
Mineral & ore processing
Tailing disposal
Soil washing& remediation
Concrete wash-out
Corrosive solids handling
