Tobee 6x4D-AH Slurry Pump Frame Plate Liner Insert E4041A05 6x4D-AH Description
Email: Sales7(at)tobeepump.com
Tobee® Frame plate liner insert E4041MA05A forms a pump chamber with throat bush and volute liner where the slurry would flow through them. Tobee offers frame plate liner inserts are interchangeable with warman pump frame plate liner inserts with high chrome, natural rubber, polyurethane for different working condition.
Frame plate liner insert is a wet part where the shaft passes through, it is drive side liner which is connected with frame plate in horizontal slurry pump.
Alloy frame plate liner insert is common in small and large pumps, but rubber frame plate liner insert appears in large pumps, because rubber frame plate liner insert and frame plate liner are normally in one solid piece in small pumps.
