Tobee 2x1.5 BAH Horizontal Slurry Pump Spares and Parts
- Product Name: Tobee 2x1.5 BAH Horizontal Slurry Pump Spares and Parts
- Model Number: 2x1.5 BAH
- Brand Name: Tobee
- Place of Origin: Hebei, China
- Minimum Order Quantity: 1
- Supply Capacity: 2000/month
- Payment: T/T
- MemberShip: Free Member
- Inquiry Now
Tobee 2x1.5 BAH Horizontal Slurry Pump Spares and Parts 2x1.5 BAH Description
Sales7(at)tobeepump.com
Tobee® 2/1.5B AH Slurry Pump is the world’s standard for heavy duties. A wide variety of impellers and shaft seals provide a perfect fit for a wide range of applications. The slurry pump provides excellent wear life while maintaining efficiency during the wear cycle providing the best total operating cost. Together with the Tobee® MC series slurry pump, the AH horizontal slurry pump provides a complete selection for most all duties in the mill. From cyclone feed to regrind, flotation and tailings, so the Tobee® AH™ slurry pump is the best choice.
• 2x1.5B AH small slurry pump is designed for the handling highly abrasive, high density slurries.
• 2X1.5B AH small slurry pump pumps of this type also can be installed in multistage series.
• The frame plates for type NH centrifugal slurry pumps have replaceable wear-resistant metal liners or rubber liners.
• The impellers are made of wear resistant chrome alloy or rubber.
• The frame plate liner and impeller for HH pump are adoptable of wear-resistant metal only .
• The shaft seals for 2X1.5B AH small slurry pumps can be adoptable of gland seal or expeller seal.
• This Series of smaller slurry pumps are also used for conveying abrasive or corrosive slurries.
Main 1.5x1B-AH Slurry Pump Parts: Impeller B1127NA, Volute Liner B1110NA, Frame Plate Liner Insert B1041NA, Cover Plate B1013, Frame Plate B1032, Expeller B028, Expeller Ring B029, Stuffing Box B078, Pump Shaft B073M, Shaft Sleeve B075, Shaft Spacer B117, Bearing Assembly B005M, Base B003M, Gland Assembly B044, Labyrinth Ring B108, End Cover B024, and so on.
Main 2x1.5B-AH Slurry Pump Parts: Pump Base B003M, Bearing Assembly B005M, Cover Plate B15013, Cover Plate Liner B15017, End Cover B024, Expeller B028, Expeller Ring B029, Frame Plate B15032, Frame Plate Liner B15036, Frame Plate Liner Insert B15041NA, Gland Assembly B044, Lantern Ring B063, Shaft Sleeve B075, Stuffing Box B078, Volute Liner B15110NA, Shaft Spacer B117, Impeller B15127NA, and so on.
