65SP vertical pumps, 100SP vertical spindle pumps, vertical sump pumps

65SP vertical pumps, 100SP vertical spindle pumps, vertical sump pumps
  • Product Name: 65SP vertical pumps, 100SP vertical spindle pumps, vertical sump pumps
  • Model Number: SP SPR
  • Brand Name: Tobee
  • Place of Origin: Hebei, China
  • Minimum Order Quantity: 1pc
  • Supply Capacity: 100000/month
  • Payment: 100T/T
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

65SP vertical pumps, 100SP vertical spindle pumps, vertical sump pumps SP SPR Description

Tobee®SP/SPR Vertical slurry pump is a cantilever sump pump,Which work submerged to transport high abrasive and high density slurries with large particles.It doesn't need any seal water. Hard metal lined or fully rubber lined fitted.High capacity double suction semi-open impeller design.and suction agitator is also available.


1.Vertical,Submerged,Cantilevered shaft sump slurry pump

2.Bearing Assembly - The bearings, shaft and housing are generously proportioned to avoid problems associated with the operation of cantilevered shafts in the first critical speed zones.

3..Column Assembly - Completely fabricated from antiwear carbon steel. The TPR model is rubber covered.

4.Shaft - Different length of the pump drive shaft or suction extension pipe could be selected

5.Casing - TP(R) has a simple bolt-on attachment to the base of the column. It is manufactured from a wear resistant alloy for the TP pump series and from moulded Rubber for the TPR pump series.

6.Impeller - Double suction semi-open impeller design, Wear resistant alloys, polyurethane and moulded elastomer impellers are interchangeable.
